TECHNICAL CHARACTERISTICS

Suitable for multi-ribbed belts, V-belts and synchronous belts.
CE approved.
RoHS 2 complaint: the device complies with the European Directive (2002/95/EC) on the restrictionof the use of certain hazardous substances in electrical and electronic equipment.
Batteries: 2 x AAA.
Measurement range: 10 Hz to 5,000 Hz.
Measured accuracy: ± 1%.
LCD screen backlight.
Double display possible (Newton and/or Hz).
Flexible flat sensor (standard
included – PN 7420-00205).
Stores weight, width and span constants for up to forty different drive systems.
Auto gain adjustment function automatically eliminates background noise.
Cord sensor and inductive sensor available on request.
Compact model (H 160 mm x D 26 mm x W 59 mm).
Use and storage temperature range: -10°C to +50°C (free from condensation).
