ABB SHD201/16 – Switch Disconnector 1P, 16A

The ABB SHD201/16 Switch Disconnector is a 1-pole, 16A isolator switch designed for safe disconnection of electrical circuits in low-voltage applications. Below is some detailed information about this product:

ABB SHD201/16 – Switch Disconnector 1P, 16A

Product Overview:

• Type: 1-pole switch disconnector (Isolator)
• Current Rating: 16 Amps (A)
• Function: The SHD201/16 is designed to manually disconnect electrical power to ensure safety during maintenance or repair work. It provides a means to isolate electrical circuits, preventing accidental switching on or usage.
• Mounting: The switch disconnector is suitable for installation on a DIN rail and complies with DIN EN 60715 for mounting depth and width.
• Color: The unit comes in grey (RAL 7035) with a red (RAL 3000) switch lever for clear visibility during operation.
• Locking: It includes a locking device feature to prevent unauthorized operation (ON/OFF), ensuring safety during maintenance.

Key Features:

1. Manual Operation: The isolator is operated manually, which allows users to safely isolate a faulty section of the circuit for repair or maintenance.
2. Safety Lock: A built-in locking mechanism ensures that the switch cannot be accidentally turned back on during maintenance, adding an extra level of protection.
3. Compact Design: The product is compact and designed for easy installation on a DIN rail, saving space and simplifying the setup in electrical panels.
4. Durability: Built with high-quality materials, the SHD201/16 is designed to endure in demanding environments, making it suitable for industrial and commercial applications.

Applications:

• Industrial Settings: Used for isolating circuits in industrial machinery and control panels, making it ideal for maintenance and emergency shutdowns.
• Electrical Panels: Perfect for use in electrical distribution panels to disconnect parts of the system safely for inspection or repair.
• Automation: Commonly used in automation systems where there is a need for reliable and safe power disconnection.

Technical Specifications:

• Mounting Depth: 70mm
• Mounting Width per Pole: 17.5mm (1 module)
• Operating Temperature: Typically -5°C to +40°C (depending on specific usage conditions)
• Electrical Lifetime: Designed for a long electrical life with high endurance under normal operating conditions.

Standards and Certifications:

• Compliant with IEC Standards: The product is compliant with international standards such as IEC 60947-3, ensuring safety and reliability.
• DIN EN 60715: Mounting compatible with DIN EN 60715 standards, which ensures the product fits in standard electrical installation systems.

Ordering Information:

• Ordering Code: 2CDD271111R0016
• Current Rating: 16A (Amps)

This switch disconnector is ideal for use in a wide range of applications, offering both performance and reliability in industrial, commercial, and residential settings.

For more details or to purchase the ABB SHD201/16, feel free to contact WOW Electricals, an authorized distributor of ABB products, or visit our website at www.wowelectricals.com.
