1SDA059796R1 ABB E2S W FP 4p HR-VR new

The 1SDA059796R1 is a fixed part from ABB’s SACE Emax E2S series, specifically designed for four-pole circuit breakers, with a unique terminal configuration to support flexible installation setups. Here’s an overview:

• Product Type: SACE Emax E2S Circuit Breaker Fixed Part
• Model Number: 1SDA059796R1
• Series: E2S – an upgraded or specialized version within the Emax series, suited for applications requiring tailored configurations or enhanced performance.
• Pole Configuration: 4-pole, making it suitable for managing and protecting four separate circuits in an electrical system.
• Terminals:
  • Upper Terminals: Horizontal configuration, which allows flexible integration in setups where horizontal connections at the top are more practical.
  • Lower Terminals: Vertical configuration, suitable for applications where a vertical alignment at the bottom improves installation and space efficiency.
• Condition: New, ensuring that it’s in perfect, unused condition for installation.
• Usage: Ideal for electrical engineers and professionals working on high-performance installations where a customized terminal layout can optimize system design. This configuration supports applications in industrial, commercial, and advanced power distribution systems where circuit protection and efficient space management are priorities.

The ABB SACE Emax E2S series is recognized for its high-quality protection features and adaptability, with this fixed part helping to optimize the circuit breaker’s performance, stability, and integration in various installation environments.
