1SDA038320R1 ABB UVD 220/250VE1/6-T7-X1-T8-E1.2/6.2-XT7/M

The 1SDA038320R1 ABB UVD Electronic Time Delay is an advanced component designed for time delay functions in ABB circuit breakers. It is used to provide precise control over the tripping action of the circuit breaker by introducing a delay in the operation of the breaker.

• Part Number: 1SDA038320R1.
• Manufacturer: ABB.

Features and Functionality

1. Electronic Time Delay:
   • The UVD (Universal Voltage Delay) is an electronic time delay module, which is used to delay the operation of the circuit breaker under specific conditions. This delay is crucial in protecting equipment and ensuring that the circuit breaker trips at the correct time during an overload or fault condition.
2. Voltage Range:
   • It supports both 220V/250V AC/DC operation, providing flexibility for use in a variety of electrical systems. This makes it adaptable to both alternating and direct current systems.
3. Compatibility:
   • The UVD module is compatible with multiple ABB circuit breakers, including:
     • E1/6, T7, T7M, X1, T8, E1.2/6.2, XT7, and XT7M series.
   • Ideal for applications where time delays are needed to ensure optimal protection against transient faults or overload conditions.
4. Adjustable Time Delay:
   • The time delay is adjustable, allowing users to set the delay according to specific operational needs, improving flexibility in protection settings.

Technical Specifications

• Model: 1SDA038320R1.
• Voltage Rating:
  • 220/250V AC/DC.
• Application Range:
  • Compatible with ABB E1/6, T7, T7M, X1, T8, E1.2/6.2, XT7, and XT7M circuit breakers.
• Time Delay:
  • Adjustable delay settings depending on the protection requirements.
• Circuit Protection:
  • Prevents immediate tripping, allowing time for the resolution of transient faults or other temporary conditions.

Applications

1. Overload Protection:
   • Used to delay the trip signal for certain types of overloads, ensuring that short-duration overloads or transient conditions do not cause unnecessary tripping.
2. Fault Isolation:
   • Enables the breaker to isolate faults in electrical circuits with a time delay, providing greater control and reducing the likelihood of nuisance trips in critical systems.
3. Industrial Automation:
   • Applied in systems requiring precise timing to coordinate multiple devices or ensure proper sequencing in automation setups.
4. Energy Management:
   • Useful in power distribution networks where avoiding unnecessary trips can prevent downtime and improve system reliability.

Benefits

1. Flexible Time Delay:
   • Adjustable settings to accommodate various protection requirements, ensuring the optimal protection of electrical systems.
2. Dual Voltage Compatibility:
   • Works with both AC and DC circuits, offering versatility across different applications.
3. Enhanced Protection:
   • Provides a controlled response to overload or short-circuit conditions, minimizing unnecessary interruptions in power supply.
4. Seamless Integration:
   • Easily integrates with ABB’s range of circuit breakers, ensuring reliable performance in industrial, commercial, and residential settings.
